Stainless steel hex bars and rods are made from high-grade stainless steel alloys that contain chromium, nickel, and molybdenum. These materials offer great corrosion resistance and strength. The alloys have high hardness, wear resistance, and toughness, which makes them suitable for challenging conditions. Their mechanical properties include high tensile strength, good elongation, and strong yield strength, ensuring a long service life. Thanks to their excellent machinability, weldability, and dimensional stability, these bars and rods work well under heavy loads and high-stress situations, making them ideal for precision engineering and industrial uses.
Stainless steel hex bars and rods are made from high-grade stainless steel alloys that contain chromium, nickel, and molybdenum. These materials offer great corrosion resistance and strength. The alloys have high hardness, wear resistance, and toughness, which makes them suitable for challenging conditions. Their mechanical properties include high tensile strength, good elongation, and strong yield strength, ensuring a long service life. Thanks to their excellent machinability, weldability, and dimensional stability, these bars and rods work well under heavy loads and high-stress situations, making them ideal for precision engineering and industrial uses.
| Name | Stainless Steel Hexagonal Bars |
| Stainless Steel Hex Bar Standard | EN, AISI, DIN, ASTM, SUS |
| Grades | 304L, 201, 202, 301, 304LN, 309S, 17L, 347, 347H, 316N, 316LN, 304, 316, 316L, 317,3 304N 310S, 316Ti, |
| Stainless Steel Hex Bar Size (Hexagonal bar) | 6 x 6 milimeter to 75 x 75 milimeter |
| Shape | Stainless steel hexagonal bar |
| Price Term | CIF/FOB/CNF or as per need |
| Stainless Steel Hex Bar Length | 5MTR, 4MTR, 6MTR, 3MTR or as per need |
| Application | Architectural Applications, Kitchen Equipment , Sanitary Wares, Furniture, Precision Engineering |
| Stainless Steel Hex Bar Certificate | NDT Test Reports, NABL Approved Lab Test Reports, IGC Practice E Test Reports, Mill TC EN 10204 3.1, |
| Grade | Si | C | Mn | Cr | Ni | N | S | P |
| SS 304 | 0.75 max | 0.03 max | 2 max | 18 – 20 | 8 – 12 | 0.10 Max | 0.030 max | 0.045 max |
| SS 304L | 0.75 max | 0.03 max | 2 max | 18 – 20 | 8 – 12 | 0.10 Max | 0.030 max | 0.045 max |
| SS 316 | 0.75 max | 0.08 max | 2 max | 15 – 18 | 10 – 14 | 0.1 Max | 0.030 max | 0.045 max |
| SS 316L | 0.75 max | 2.00 max | 18.00 max | 14.00 Max | 0.10 Max | 0.1 Max | 0.030 max | 0.045 max |
| Grade | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Density | Melting Point |
| SS 304 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40% | 8.0 g/cm3 | 1400 °C (2550 °F) |
| SS 304L | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40% | 8.0 g/cm3 | 1400 °C (2550 °F) |
| SS 316 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % | 8.0 g/cm3 | 1454 °C (2650 °F) |
| SS 316L | 485 Min | 170 Min. | 40 % | 8.0 g/cm3 | 1400 °C (2550 °F) |
| Length in inch | Size in Inch | Weight (lbs/ft) |
|---|---|---|
| 144 | 1/4 | .180 |
| 3/8 | .415 | |
| 7/16 | .565 | |
| 1/2 | .735 | |
| 9/16 | .930 | |
| 5/8 | 1.15 | |
| 11/16 | 1.390 | |
| 3/4 | 1.655 | |
| 7/8 | 2.255 | |
| 1 | 2.945 | |
| 1-1/16 | 3.31 | |
| 1-1/8 | 3.73 | |
| 1-1/4 | 4.60 | |
| 1-3/8 | 5.58 | |
| 1-1/2 | 6.63 | |
| 1-5/8 | 7.78 | |
| 2 | 11.79 | |
| 4 | 47.160 |
| Sizes in Inch | Stainless Steel Hex Bar Sizes In inch |
| H-1/8 | 1/8 |
| H-1/4 | 1/4 |
| H-5/32 | 5/32 |
| H-3/16 | 3/16 |
| H-7/32 | 7/32 |
| H-5/16 | 5/16 |
| H-3/8 | 3/8 |
| H-7/16 | 7/16 |
| H-7/8 | 7/8 |
| H-1/2 | 1/2 |
| H-9/16 | 9/16 |
| H-5/8 | 5/8 |
| H-11/16 | 11/16 |
| H-3/4 | 3/4 |
| H-1 | 1 |
| H-1-1/8 | 1-1/8 |
| H-1-1/4 | 1-1/4 |
| H-2 | 2 |
| H-1-3/8 | 1-3/8 |
| H-1-1/2 | 1-1/2 |
| H-1-5/8 | 1-5/8 |
| H-1-3/4 | 1-3/4 |
| H-1-7/8 | 1-7/8 |
| H-2-1/4 | 2-1/4 |
| H-2-3/4 | 2-3/4 |
| H-2-1/2 | 2-1/2 |
| H-3 | 3 |
| Section | Size, diameter | Permitted overall variation | ||
| Class A | Class B | Class C | ||
| mm | mm | mm | mm | |
| Round | ≧ 6 <75 | 0.05 | 0.025 | 0.013 |
Stainless steel hex bars and rods come in various grades, including 304, 316, 410, 416, 420, and 630. They vary in corrosion resistance, strength, and hardness. Common types include austenitic, ferritic, martensitic, and precipitation-hardening stainless steels, each suited for different applications in manufacturing, construction, and marine environments.
In the Turkey, you can buy high-quality stainless steel (SS) hex bars and rods from suppliers such as Metal Supermarkets, 304 Stainless Steel, or Aalco Metals. They offer a wide selection of sizes and grades. Other reputable suppliers include Buy Metal Online, Steel Express, and Turkey Steel. Ensure to check their specifications for the exact product you need.
Yes, many Turkey suppliers offer 316 stainless steel hex bars and rods in custom sizes and finishes. Companies like Metal Supermarkets, Buy Metal Online, and Steel Express provide tailored options, including specific lengths, diameters, and polished finishes. Contacting the supplier directly allows you to request personalized products to meet your specific requirements for projects.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
