Semih Metals is a trusted supplier and exporter of SS 430 Hex Bars, a ferritic chromium steel renowned for its superior corrosion resistance. These SS 430 Hex Bars find extensive application in industries ranging from automotive trims and household appliances to architectural components, dryer and dishwasher interiors, fuel burner parts, and more. Comprising 16% chromium, this versatile alloy is particularly suited for use in catering equipment, home appliances, and indoor installations. Grade 430 Hex Bars are valued for their optimal combination of corrosion resistance, formability, and reliable mechanical properties. In their annealed state, these bars demonstrate excellent ductility, making them ideal for cold working processes. They are easily shaped using roll forming, mild stretch bending, as well as standard drawing and bending techniques, ensuring broad adaptability across multiple sectors.
SS 430 Hex Bars are composed primarily of 16% chromium with trace amounts of manganese, silicon, and carbon, enhancing corrosion resistance and strength. The alloy exhibits a tensile strength of approximately 450 MPa and a yield strength of 275 MPa, with an elongation of 22% in annealed conditions. SS 430 Hex Bars have a Brinell hardness of 150 HB, offering a good balance of strength and formability. This ferritic stainless steel is magnetic, possesses excellent oxidation resistance, and maintains stability up to 815°C, making it suitable for various industrial applications.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 430 | 0.12 | 18.0 | 1.25 | – | 0.06 | 0.15 | 1.00 |
| Element | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness (Brinell (HB) max) |
| SS 430 | 552 | 379 | 25 | 262 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 430 hex bars are widely used in automotive, kitchen appliances, construction, and decorative industries due to their corrosion resistance, formability, and cost-effectiveness. Their magnetic properties and durability make them ideal for functional and aesthetic applications.
SS 430 hex bars offer moderate corrosion resistance, suitable for mildly corrosive environments. They perform well in indoor and dry settings but may corrode in marine or highly acidic conditions. Proper environmental assessment ensures optimal material performance and longevity.
SS 430 Hex Bars are widely utilized across various industries due to their corrosion resistance and mechanical properties. In the automotive sector, they are used for trims and exhaust systems. Household applications include interiors of dishwashers, dryers, and other appliances. Architectural components such as decorative trims and structural elements benefit from their aesthetic and durable nature. SS 430 Hex Bars are also ideal for catering equipment, fuel burner parts, and indoor installations. Their adaptability to cold working processes makes them suitable for diverse forming and fabrication techniques.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
