Semih Metals manufactures leading stainless steel 410 hex bars, offering excellent strength and hardness combined with moderate corrosion resistance These SS 410 Hex Bars are chromium-containing, strength-enhancing martensitic stainless steel reliable corrosion resistance in a variety of environments. Our alloy 410 hex bars are resistant to mild acids, water, air, and certain chemicals, making them suitable for a wide range of applications including fasteners, hardware brackets, springs, scrapers, and furnace parts. Known for superior post-heat machining, our Grade 410 Hex lumber provides durability and corrosion resistance. These rods are ideal where strength, rigidity and resistance are required along with corrosion protection. Additionally, the forging temperature for Type 410 hex bars should not be less than 1650°F (900°C) to ensure proper operation. Semih Metals ensures the highest quality and highest performance in every product, meeting the demands of a variety of industrial applications.
SS 410 Hex Bars are composed primarily of 11.5-13.5% chromium, with small amounts of carbon (0.08% max), manganese, silicon, phosphorus, sulfur, and nickel. This composition provides a balance of strength, hardness, and corrosion resistance. Mechanically, SS 410 offers a tensile strength of 70-90 ksi (485-620 MPa), yield strength of 30-60 ksi (205-415 MPa), and hardness ranging from 35-50 HRC after heat treatment. It is suitable for applications requiring high strength, wear resistance, and moderate corrosion resistance, especially in mildly corrosive environments.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 410 | 0.15 | 11.5-13.5 | 1.00 | 0.75 | 0.040 | 0.030 | 1.00 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 410 Hex Bar has moderate corrosion resistance compared to other stainless steels like 304 or 316. It is susceptible to corrosion in chloride-rich environments and high-temperature conditions, making it less suitable for highly corrosive or marine applications.
SS 410 Hex Bar's hardness requires careful machining, as it can be challenging to cut and grind. High cutting speeds, proper tooling, and coolant usage are essential to prevent work hardening, ensure smooth surfaces, and extend tool life during processing.
SS 410 Hex Bars are widely used in applications requiring a combination of strength, hardness, and moderate corrosion resistance. Common uses include fasteners, hardware brackets, springs, scrapers, furnace parts, and burners. They are also employed in the manufacturing of valves, pumps, and shafts, especially in environments exposed to mild acids, water, and air. Due to their heat treatability, SS 410 Hex Bars are ideal for applications where wear resistance and mechanical strength are crucial, such as in the automotive, petrochemical, and manufacturing industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
