Semih Metals, located in Istanbul, Turkey, is a trusted manufacturer and supplier of Aluminium 1050 Forgings. They provide top-notch aluminum alloy products that are crafted for outstanding corrosion resistance, ductility, and thermal conductivity. With a focus on precision and rigorous quality control, these forgings deliver remarkable dimensional accuracy, a smooth surface finish, and reliable performance. Semih Metals guarantees that their Aluminium 1050 Forgings meet the needs of various industries, including chemical processing, food and beverage, architecture, and electrical sectors, where lightweight, corrosion-resistant, and highly formable materials are crucial.
Aluminium 1050 Forgings are mainly made from high-purity aluminum (≥99.5%), with just a touch of iron and silicon. This unique blend offers exceptional corrosion resistance in both atmospheric and chemical settings, along with excellent electrical and thermal conductivity, and impressive ductility. Mechanically, Aluminium 1050 boasts moderate tensile strength, good machinability, and superb workability, making it perfect for forming, bending, and welding tasks. While it may not be as strong as some other alloys, its outstanding corrosion resistance and conductivity make it incredibly versatile.
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S |
Yes, Aluminum 1050 forgings can be shaped into custom designs through processes like open-die and closed-die forging, allowing for precise, unique shapes tailored to specific applications.
The ideal temperature range for forging Aluminium 1050 forgings is between 350°C to 500°C (660°F to 930°F), ensuring optimal material flow and minimizing the risk of cracking or deformation.
These Aluminium 1050 Forgings find their place in industries that demand lightweight, corrosion-resistant, and conductive materials. They’re frequently used in chemical processing equipment, machinery for the food industry, heat exchangers, electrical conductors, and decorative architectural elements. Moreover, they serve in storage tanks, pressure vessels, and general engineering applications where formability and corrosion resistance take precedence over sheer strength. Thanks to their excellent mix of corrosion resistance, ductility, and conductivity, Aluminium 1050 Forgings ensure dependable and long-lasting performance across industrial, structural, and chemical applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
