Semih Metals, located in Istanbul, Turkey, is a reliable manufacturer and supplier of Aluminium 6063 Bars and Rods. They offer top-notch aluminum alloy products that are designed for excellent corrosion resistance, solid mechanical strength, and impressive formability. Crafted with precision and under strict quality control, these bars and rods boast exceptional dimensional accuracy, a smooth surface finish, and dependable performance. Semih Metals guarantees that their Aluminium 6063 Bars and Rods meet the high standards required by various industries, including construction, automotive, aerospace, and architectural applications, where lightweight, durable, and corrosion-resistant materials are a must.
The composition of Aluminium 6063 Bars and Rods primarily includes aluminum (around 97%), magnesium (approximately 0.45–0.9%), and silicon (about 0.2–0.6%), along with trace amounts of other elements. This blend offers remarkable corrosion resistance, especially in atmospheric and marine settings, as well as good tensile and yield strength. On the mechanical side, 6063 is known for its excellent ductility, machinability, and fatigue resistance, making it ideal for forming, bending, and welding tasks, as well as for structural and decorative uses.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Cu | Si | Fe | Mn | Mg | Zn | Cr | Ti | Other Each | Others Total | Al |
| .10 (max) | .20/.60 | .35 (max) | .10 (max) | .45/.90 | .10 (max) | .10 (max) | .10 (max) | .05 | .015 | Remainder |
| Tensile Strength (psi) | Yield Strength (psi) | Elongation (% in 2″) | Brinell Hardness |
| 27,000 | 21,000 | 12 | 60 |
| UNS | EN | DIN, WNR | ISO | BS (OLD) | USA | WNR |
| A96063 | AW-AlMg0,7Si EN AW-6063 | AlMgSi0.5 | AlMg0,7Si | HE9 | AA6063 | 3.32206 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 6063 rods can be customized in size and length according to specific requirements. Manufacturers offer flexibility in dimensions to meet various application needs and industry standards.
To maintain Aluminium 6063 bars, clean regularly with mild soap and water, avoid harsh chemicals, and inspect for scratches or corrosion. For enhanced longevity, apply a protective coating if needed.
Yes, Aluminium 6063 bars are highly recyclable. Aluminium can be reused indefinitely without losing quality, making it an eco-friendly choice. Recycling helps conserve resources and reduces energy consumption in production.
Aluminium 6063 Bars and Rods find extensive application in industries that need lightweight, corrosion-resistant, and versatile materials. They are frequently used in architectural frameworks, window and door profiles, automotive parts, piping systems, and marine structures. Moreover, they play a role in aerospace components, structural supports, and transportation equipment where strength, durability, and corrosion resistance are crucial. With their blend of mechanical strength, corrosion resistance, and formability, Aluminium 6063 Bars and Rods deliver long-lasting performance across industrial, architectural, and structural applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
