Semih Metals, located in Istanbul, Turkey, is a reliable manufacturer and supplier of Aluminium 5754 Bars and Rods. They offer top-notch aluminum alloy products that are designed for exceptional corrosion resistance, mechanical strength, and formability. Crafted with precision and under strict quality control, these bars and rods boast impressive dimensional accuracy, a smooth surface finish, and dependable performance. Semih Metals guarantees that their Aluminium 5754 Bars and Rods meet the high standards required by industries like marine, automotive, aerospace, and chemical processing, where durable and lightweight materials are a must.
The composition of Aluminium 5754 Bars and Rods includes approximately 94.5–95.5% aluminum, 2.6–3.6% magnesium, and trace amounts of manganese (around 0.3–0.5%). This blend offers remarkable corrosion resistance, especially in marine and chloride-rich settings, while also providing good tensile strength and fatigue resistance. Mechanically, 5754 is known for its high ductility, weldability, and stability, making it ideal for forming, bending, and fabrication in both structural and industrial contexts.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Mg | Mn | Si | Cu | Fe | Cr | Zn | Ti | Cu | Other (Each) | Others (Total) | Al |
| 2.60 – 3.60 | 0.0 – 0.50 | 0.0 – 0.40 | 0.0 – 0.40 | 0.0 – 0.30 | 0.0 – 0.20 | 0.0 – 0.15 | 0.0 – 0.10 | 0.0 – 0.05 | 0.0 – 0.05 | 0.0 – 0.15 | Balance |
| Proof Stress | Tensile Strength | Elongation at 50 mm | Hardness Brinell |
| 80 Min MPa | 190 – 260MPa | 12 Min % | 52 HB |
| UNS | EN | DIN | ISO | USA | WNR |
| A95754 | EN AW-5754 | AlMg3 | AlMg3 | AA5754 | 3.3535 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 5754 bars and rods are suitable for structural applications due to their excellent strength, corrosion resistance, and formability, making them ideal for use in marine, automotive, and architectural structures.
Yes, Aluminium 5754 bars can be welded using various techniques, such as MIG and TIG welding. However, proper welding procedures and equipment are essential to maintain its strength and integrity.
Aluminium 5754 bars are typically sized based on diameter and length. The diameter can range from a few millimeters to several inches, while the length is often available in standard lengths, typically up to 6 meters. Custom sizes can also be ordered based on specific requirements. The bars are available in various shapes, including round, square, and hexagonal, to suit different applications.
These Aluminium 5754 Bars and Rods find extensive use in industries that demand strong, corrosion-resistant materials. They’re commonly utilized in shipbuilding, marine hardware, automotive body panels, pressure vessels, and transportation equipment. Furthermore, they play a role in chemical processing equipment, architectural frameworks, aerospace structures, and industrial machinery, where durability, corrosion resistance, and workability are crucial. With their excellent combination of strength, corrosion resistance, and formability, Aluminium 5754 Bars and Rods provide long-lasting performance in challenging industrial, marine, and structural applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
