Semih Metals is one of the best manufacturers and suppliers of quality metal products based in Istanbul, Turkey. Among the metal products they supply Aluminium 2024 bar and rod. Precision, durability, and excellent performance characterize this type of aluminum 2024. Its high strength-to-weight ratio and resistance to corrosion make it an excellent product for aerospace, automotive, and structural applications. Semih Metals strives to deliver exceptional quality and prompt service with any custom size for each client in a timely fashion. With so many years of experience and maintaining a customer-orientated mentality, Semih Metals is the source of choice among industries for first-class metal solutions and customized application.
Aluminium 2024 bars and rods are comprised primarily of aluminum, with an aluminium content between 90.7-95.3% by weight and with key alloying elements in the form of copper (3.8-4.9%), manganese (1.2-1.8%), and magnesium (1.2-1.8%). It contains other elements at levels of less than 0.5%, namely silicon and iron. Its mechanical properties have enabled Aluminium 2024 to offer high strength, excellent fatigue resistance, and good machinability. The tensile strength is around 470 MPa, yield strength is about 324 MPa, and elongation is of 20%. Such properties make this material specifically useful for aerospace or military applications where strength and durability at all levels are critical.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 2024 | A92024 | 3.1355 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 2024 can be welded, but it is challenging due to its susceptibility to cracking. Specialized techniques like TIG welding with proper filler material and preheating are recommended for best results.
To maintain Aluminium 2024 bars, regularly clean with mild detergent, avoid exposure to harsh chemicals, and apply protective coatings. Store in dry conditions to prevent moisture and corrosion, ensuring longevity.
Yes, Aluminium 2024 can corrode, especially in harsh environments. It has moderate resistance to corrosion, but its susceptibility increases without proper protective coatings, making it prone to pitting and stress corrosion cracking.
Aluminium 2024 bars and rods are extensively used for applications in industries which need high strength low weight materials excellent fatigue resistance. It is used in aerospace applications such as structures, wings, fuselages, and engine components due to its ability to tolerate very heavy-duty high-stress environments. It is also used by the military in most weaponry and vehicles. Aluminium 2024 is also used for transportation components such as marine and automotive structures. It possesses very high resistance to corrosion while at the same time being highly machinable, making it suitable for precision parts, including fasteners, gears, and shafts, into high-performance engineering sectors.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
