Semih Metals, based in Istanbul, Turkey, is a trusted producer and supplier of Titanium Grade 1 bars and rods, providing high-quality products for industries demanding superior corrosion resistance and formability. With an emphasis on precision production and international quality norms, Semih Metals provides Titanium Grade 1 bars and rods with good performance in highly corrosive conditions. The firm is catering to a broad client base covering chemical processing, marine, medical, and industrial engineering sectors. With advanced production methods and rigorous quality checks, Semih Metals provides uniform performance, dimensional precision, and extended service life across all product lines.
Titanium Grade 1 is the most ductile and soft among the commercially pure titanium grades and is an excellent material for welding, forming, and machining. It has superior corrosion resistance, especially in oxidizing and weakly reducing environments. The mechanical properties consist of a tensile strength of around 240–350 MPa and a yield strength of around 170 MPa, with elongation values of up to 24%. Although less strong than other grades, its excellent corrosion resistance and excellent ductility make it perfect for use in applications where forming and welding are desired without sacrificing corrosion performance.
| Standards : | ASTM B348, B863 / ASME SB 348, SB 863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr 1 | 3.7025 | R50250 |
| Grade | C | N | O | H | Ti | Fe |
| Titanium Grade 1 | 0.08 max | 0.03 max | 0.18 max | 0.015 max | Bal | 0.20 20 |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 240 | 170 | 24 % |
| Physical Properties | Metric | English |
|---|---|---|
| Density | 4.51 g/cc | 0.163 lb/in³ |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Titanium Grade 1 Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@semihmetal.com
Titanium Grade 1 rods and bars find extensive application in those fields where high corrosion resistance, ductility, and facile fabricability are requirements. In the chemicals industry, they find application in heat exchangers, tanks, piping systems, and linings that come into contact with corrosive media. Seawater-resistant parts like fittings and pump components find suitable application in coastal environments. The medical sector takes advantage of their biocompatibility for surgical instruments and implantable hardware. Grade 1 is also employed in desalination, aerospace, and architectural uses where low strength is acceptable but formability and corrosion resistance are essential.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
