Semih Metals, Istanbul, Turkey, is a well-known manufacturer and supplier of Titanium Grade 11 forgings, providing high-quality titanium components with improved corrosion resistance in harsh environments. Using advanced forging technology and rigorous quality control, Semih Metals guarantees that every Grade 11 titanium forging meets international standards and customer requirements. Used in industries like chemical processing, marine, power generation, and desalination, the company delivers long-lasting, dependable forgings that offer strength, toughness, and superior resistance to reducing and acidic environments.
Titanium Grade 11 forgings consist of commercially pure titanium alloyed with a small percentage of palladium (0.12–0.25%), which provides extreme resistance to crevice corrosion, pitting, and stress corrosion cracking. Such forgings have tensile strengths of 240 to 350 MPa and yield strengths of approximately 170 MPa, with elongation to 24%. The process improves mechanical properties through grain refinement of the structure, increased toughness without compromising the enhanced corrosion resistance inherent in Grade 11 titanium. It also possesses excellent formability and weldability for complex and critical parts.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 11 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | 12 – .25 |
| Grade | Tensile Strength min | Yield Strength (0.2 % Offset) | Elongation | Reduction of Area | ||
| ksi | Mpa | ksi | Mpa | min % | min % | |
| 11 | 35 | 240 | 25 | 170 | 24 | 30 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 11 | 3.7225 | R52550 |
Yes, Titanium Gr 11 forgings are highly corrosion-resistant, especially to oxidizing environments and seawater. This makes them ideal for applications in industries like aerospace, marine, and chemical processing, ensuring long-lasting durability.
Titanium Gr 11 forgings are commonly used in industries such as aerospace, marine, chemical processing, medical, and power generation. Their strength, corrosion resistance, and high-performance capabilities make them ideal for demanding applications.
Yes, Titanium Gr 11 forgings can be customized for specific applications, offering tailored sizes, shapes, and properties to meet unique industry requirements, ensuring optimal performance and reliability in demanding environments.
Titanium Grade 11 forgings find extensive application in those industries that require enhanced corrosion resistance under aggressive chemical conditions. They are suitable for chemical processing equipment including heat exchangers, reactors, and piping handling chlorides and acidic solutions. Grade 11 forgings are applied in marine use in seawater and brine-exposed components that need long service life. They are also utilized in desalination plants, pollution abatement systems, and offshore platforms. Their resistance to harsh media and capability to retain mechanical integrity make Grade 11 forgings appropriate for severe, high-performance uses.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
