Semih Metals, Istanbul, Turkey, is a prominent manufacturer and exporter of Super Duplex Steel bars and rods, providing high-strength corrosion-resistant stainless steel products customized for aggressive industrial applications. Recognized for the integration of superior strength with improved pitting, crevice corrosion, and stress corrosion cracking resistance, Semih Metals supplies Super Duplex Steel bars and rods adhering to international standards and customer requirements. Supplied to industries like oil and gas, chemical process, marine, and power generation, the company provides dependable, long-lasting material that excels in hostile, aggressive conditions.
Bars and rods of Super Duplex Steel are manufactured from a stainless steel alloy with a balanced microstructure of about 50% ferrite and 50% austenite. The alloy has high tensile strength, usually in the range of 800–1,000 MPa, along with superior toughness and ductility. Super Duplex steels have chromium (20-28%), molybdenum (3-5%), and nitrogen, all of which increase their resistance to localized corrosion, particularly in chloride environments. Their mechanical properties and corrosion resistance are greater than conventional austenitic and ferritic stainless steels, and hence they can be used in demanding applications.
Specifications : ASTM A276, ASME SA276
Standard : ASTM, ASME
Size : 6 mm to 120 mm.
Length : 1 to 6 Meters, Custom Cut Lengths
Dimensions : EN, DIN, JIS, ASTM, BS, ASME, AISI
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32750 | 0.030 max | 1.20 max | 0.80 max | 0.035 max | 0.020 max | 24.00 – 26.00 | 3.00 – 5.00 | 6.00 – 8.00 | 0.24 – 0.32 | 58.095 min |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Element | S32760 |
| 0.2% Proof Stress (N/mm2 ) [ksi] minimum | 550 [79.8] |
| Ultimate Tensile Strength (N/mm2) [ksi] minimum | 750 [108.8] |
| Elongation (%) minimum | 25 |
| Reduction of Cross Section Area (%) minimum | 45 |
| Hardness (HBN) | 270max |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32750/S32760 | 1.4410 | S32750 / S32760 |
Super Duplex Steel rods are generally resistant to galvanic corrosion due to their high chromium and molybdenum content. However, they can still be susceptible when coupled with highly dissimilar metals in certain environments.
Yes, Super Duplex Steel bars can be welded using appropriate techniques and filler materials. Careful control of heat input and post-weld heat treatment is essential to avoid degradation of their mechanical properties.
Super Duplex Steel rods are available in various sizes, ranging from small diameters to large rods, typically up to 300mm or more. Finishes can include hot-rolled, cold-drawn, polished, or ground, depending on the application requirements.
Super Duplex Steel bars and rods find extensive use in high-strength applications where better corrosion resistance is needed. They are widely used in oil and gas equipment components like subsea, pipelines, and valves that are subjected to hostile seawater and sour gas conditions. In chemical processing, they are applied for heat exchangers, reactors, and piping systems that deal with corrosive chemicals. They are used in shipbuilding and offshore platforms in marine, and power generation utilizes Super Duplex Steel in condensers and cooling systems. Their resistance to harsh conditions guarantees extended service life with minimized maintenance cost in harsh industrial environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
