Semih Metals, located in Istanbul, Turkey, is a reliable manufacturer and supplier of high-quality stainless steel forgings, with a focus on Stainless Steel XM19 Forgings. The company emphasizes quality, precision, and innovation. Semih Metals provides products that meet international standards and cater to various industrial needs. Known for their durability, corrosion resistance, and excellent mechanical performance, XM19 forgings are designed for demanding applications. By using modern technology and decades of experience, Semih Metals ensures customer satisfaction with personalized solutions that improve operational efficiency in industries such as marine, petrochemical, power generation, and heavy engineering.
Stainless Steel XM19 Forgings, also called Nitronic 50, have a balanced mix of chromium, nickel, molybdenum, and nitrogen, which improves strength and corrosion resistance. They typically contain about 20 to 23% chromium, 11 to 13% nickel, 4 to 6% manganese, 1.5 to 3% molybdenum, and nitrogen for better toughness. XM19 has twice the yield strength of standard stainless steels while still being highly ductile and non-magnetic. It shows excellent resistance to pitting, crevice corrosion, and chloride stress cracking, even in tough environments. Its mechanical properties include high tensile strength, good impact resistance, and durability, making it a dependable forging material.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
| SS XM19 | 0.06 max | 0.10 max | 0.1 max | – | 0.03 max | 20.50 – 23.50 | – | 11.50 – 13.50 |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| ksi – 95 | ksi – 50 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS XM19 | 1.3964 | S20910 |
The forging process for Stainless Steel XM19 typically takes several hours, depending on the size and complexity of the part. Heating, shaping, and cooling stages contribute to the overall duration.
The ideal temperature range for forging Stainless Steel XM19 is between 2100°F to 2200°F (1149°C to 1204°C). It's important to maintain proper cooling to avoid distortion or cracking.
Yes, Stainless Steel XM19 (a high-strength alloy) can be forged into custom shapes. It offers excellent formability, allowing manufacturers to create parts with specific dimensions and designs as needed.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Semih Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Istanbul, Turkey
