Semih Metals is one of the top manufacturers and suppliers of stainless steel 416 square bars and rods from Istanbul, Turkey. The company has built a reputation for quality with the focus on excellence, offering high-grade stainless steel products that cater to various industrial uses. Our Stainless Steel 416 Square Bars and Rods are engineered with superior corrosion resistance, strength, and machinability for a range of uses in the automotive, aerospace, and manufacturing sectors. We focus on precision, durability, and timely delivery to ensure the quality and performance of our client’s products to the highest possible standards. Semih Metals takes pride in offering superior service and reliable solutions that meet the needs of our customers.
Stainless Steel 416 Square Bars and Rods consist of iron, chromium 12-14%, carbon 0.15%, manganese, silicon, and sulfur in traces. This is a martensitic alloy with good hardness and strength after heat treatment. Mechanical properties are tensile strength between 550-750 MPa, yield strength at 205 MPa, and hardness 50-55 HRC. Some advantages include excellent machinability, high strength, moderate corrosion resistance, and good wear resistance. It is also used in a wide range of applications such as valves, pumps, fasteners, and shafts where machining is critical and a moderate level of corrosion resistance is required.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 416 | 0.15 | 14.0 – 12.0 | 1.25 | – | 0.06 | 0.15 | 1 |
| Element | Density, lb/in3 | Melting Point | Electrical Resistivity |
| SS 416 | 0.282 lbs/in3 7 .80 g/cm3 | 2700 – 2790 °F (1488 – 1530 °C) | At 70 °F (21 °C): 343.0 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 416 | 1.4005 | S41600 | SUS 416 | 416S21 | – | – | X12CrS13 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 416 square bars are susceptible to galvanic corrosion when in contact with more noble metals, such as copper or brass, in the presence of an electrolyte. Proper insulation and material selection can help mitigate this risk.
Yes, we provide 416 Stainless Steel Square Bars and Rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@semihmetal.com
Stainless Steel 416 square rods are available in various sizes, typically ranging from 1/4" to 6" in width. They come in finishes like cold-finished, hot-rolled, or polished, depending on the application requirements.
Stainless Steel 416 square bars and rods are widely used in applications requiring high strength, excellent machinability, and resistance to corrosion. The common applications include manufacturing valves, pumps, and fasteners, especially in the automotive, aerospace, and marine industries. Because of its high hardness, 416 stainless steel is ideal for components like shafts, gears, and collets. It is also used to make tools and precision instruments along with hardware of oil and gas, chemical industries, and food processing. It also has resistance towards moderate corrosion besides retaining its strength at high temperature, making it suitable for use in aggressive conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
