Semih Metals, located in Istanbul, Turkey, has earned a solid reputation as a reliable manufacturer and supplier of top-notch stainless steel products, including Stainless Steel 304H Bars and Rods. With a keen emphasis on precision engineering and high material standards, the company serves industries that demand durable and heat-resistant stainless steel solutions. Their Stainless Steel 304H Bars and Rods are crafted using advanced techniques, guaranteeing impressive strength, precise dimensions, and excellent corrosion resistance. Dedicated to customer satisfaction, Semih Metals offers customized solutions to meet the diverse needs of various sectors, making them a trustworthy partner for both local and international markets.
The Stainless Steel 304H Bars and Rods primarily consist of chromium (18–20%) and nickel (8–11%), featuring a higher carbon content compared to the 304/304L grades, which boosts their strength and heat resistance. They showcase remarkable mechanical properties, boasting a tensile strength of about 515 MPa, a yield strength of roughly 205 MPa, and an elongation of 40%. This material is known for its outstanding toughness, good oxidation resistance up to 870°C, and excellent formability. The combination of durability, hardness, and thermal stability makes 304H Bars and Rods ideal for high-temperature and heavy-duty applications across various industrial settings.
| Grade | Stainless Steel 304H (UNS S30409) |
|---|---|
| Specification | ASTM A276, ASTM A479 |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Hollow Bar | 32 OD x 16 ID to 250 OD x 200 ID |
| Square bar size | 4 to 100mm |
| Section | 3.0 to 12.0mm thickness |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Billet Size | 1/2″ to 495mm Diameter |
| Channel Bar | 80 x 40 to 150 x 75 mm section; 5 to 6 mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Angle bar size | 3*20*2~12*100*100 mm |
| Form | Rings, Profiles, Hollow, Flat Bar, Square, Round, Rectangle, Triangle, Rod, Half Round Bar, T-Bar, Hex (A/F), Precision Ground Bar, Channel Bar, Blocks, Round Rod, Threaded, Billet, Ingot, I/H Bar, Forging etc. |
| Technique | Cold Drawn, Rod, Hot Rolled, Cold Rolled, Forged Round Bar |
| Condition | annealed, Hardened & tempered |
| Surface | Cold Drawn, Polished, Bright, Hot Rolled Pickled, Sand Blasting Finished,Hairline |
| Element | SS 304H |
| C | 0.10 max |
| Ni | 8.0 – 10.5 |
| P | 0.045 max. |
| Mn | 2.00 max |
| Si | 0.75 max |
| S | 0.03 max. |
| Cr | 18.0 – 20.0 |
| Element | SS 304H |
| Melting Point | 1400 ℃ |
| Density | 8 |
| Hardness (Brinell) | 201 |
| Yield Strength (0.2%Offset) | 205 |
| Tensile Strength | 515 |
| Elongation | 40 |
|
Type |
SIZES (Inches) |
ISO Tolerance |
SIZES (mm) |
|---|---|---|---|
|
Peeled and Polished |
1.50″ to 6.00″ |
h11-DIN 1013 |
40.00 to 150.00 |
|
Cold Drawn and Ground |
5/6″ to 2.50″ |
h9-h8-h11-h10 |
10.00 to 75.00 |
|
Cold Drawn and Polish |
1/8″ to 3.00″ |
h9-h8-h11-h10 |
3.00 to 75.00 |
|
Peeled and Ground |
3/4″ to 2.00″ |
h10-h9-h11 |
20.00 to 50.00 |
| STANDARD | UNS | WERKSTOFF NR. |
| SS 304H | S30409 | 1.4301 |
Stainless Steel 304H has a higher carbon content (0.04–0.10%), which enhances its strength and heat resistance, making it suitable for high-temperature applications compared to 304 and 304L.
Industries such as petrochemical, power generation, chemical processing, and construction use Stainless Steel 304H for applications like heat exchangers, boilers, pressure vessels, and structural components.
Yes, Stainless Steel 304H is designed for excellent performance in high-temperature environments, maintaining strength and corrosion resistance in conditions up to 870°C (1600°F).
Stainless Steel 304H Bars and Rods find extensive use in industries that require high-temperature strength and corrosion resistance. They are commonly utilized in heat exchangers, boilers, condensers, and pressure vessels, particularly in chemical, petrochemical, and power generation plants. Their exceptional performance in high-heat environments makes them perfect for furnace parts, superheaters, and heat treatment equipment. Additionally, they play a vital role in the food processing, oil and gas, and pharmaceutical industries, providing reliable structural and operational support. Their versatility, along with resistance to scaling and oxidation, ensures they remain durable and efficient in demanding industrial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
