Semih Metals, based in Istanbul, Turkey, has built a solid reputation as a reliable manufacturer and supplier of high-performance alloy products, including Hastelloy Hex Bars. Known for their precision-engineered materials, Semih Metals caters to industries that require outstanding corrosion resistance and mechanical reliability. With a strong focus on specialty alloys, the company supplies Hastelloy Hex Bars to clients in sectors like chemical processing, marine, aerospace, and power generation. These hexagonal bars are designed to meet rigorous international standards, ensuring superior machinability, strength, and resilience in tough environments. Semih Metals is dedicated to maintaining quality, timely deliveries, and customer satisfaction across global markets.
Hastelloy Hex Bars are crafted from a range of corrosion-resistant metal alloys, primarily made up of nickel (Ni), molybdenum (Mo), chromium (Cr), iron (Fe), and sometimes small amounts of cobalt (Co) or tungsten (W), depending on the specific grade (like C-22, C-276, or X). These bars boast excellent resistance to both oxidizing and reducing agents, along with impressive mechanical properties such as high tensile strength (usually between 690–785 MPa), good ductility, and stability even at elevated temperatures. The hexagonal design not only adds strength and rigidity but also makes them perfect for precision machining. Their remarkable corrosion resistance and mechanical integrity make them a top choice for demanding chemical applications.
| Hastelloy Hex Bar Standard | ASTM B574, AMS 5513, AMS 5511, AMS 5647 |
| Alloy Hex Bar Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Alloy Hex Rod size | 4 to 100mm |
| Alloy Hex Bars Section | 3.0 to 12.0mm thickness |
| Bar Form | Hexagonal |
| Material | Ni | C | Cr | Co | Fe | Mn | Mo | P | Si | S | W | V |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Hastelloy | Bal | 0.010 max | 20 – 22.5 | 2.5 max | 2 – 6 | 0.50 max | 12.5 – 14.5 | 0.02 max | 0.08 max | 0.02 max | 2.5 – 3.5 | 0.35 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
|
Wt per Foot t of hex bar |
Size in Inches of hex bar |
Wt per 12 ‘ of hex bar |
|---|---|---|
|
0.0180 |
1/4″ |
2.160 |
|
0.0104 |
3/16″ |
1.248 |
|
0.0600 |
3/8″ |
4.920 |
|
0.0290 |
5/16″ |
3.480 |
|
0.0740 |
1/2″ |
8.880 |
|
0.0560 |
7/16″ |
6.72 |
|
1.150 |
5/8″ |
13.80 |
|
0.0930 |
9/16″ |
11.16 |
|
1.660 |
3/4″ |
19.92 |
|
1.390 |
11/16″ |
16.68 |
|
2.300 |
7/8″ |
27.60 |
|
2.600 |
15/16″ |
31.20 |
|
1.950 |
13/16″ |
23.40 |
|
3.30 |
1-1/16″ |
39.60 |
|
2.90 |
1″ |
34.80 |
|
4.600 |
1-1/4″ |
55.20 |
|
3.700 |
1-1/8″ |
44.40 |
|
5.600 |
1-3/8″ |
67.20 |
|
5.100 |
1-5/16″ |
61.20 |
|
6.600 |
1-1/2″ |
79.20 |
|
6.100 |
1-7/16″ |
73.20 |
|
26.53 |
3″ |
318.36 |
|
9.030 |
1-3/4″ |
108.36 |
|
7.800 |
1-5/8″ |
93.60 |
|
18.42 |
2-1/2″ |
221.04 |
|
11.80 |
2″ |
141.60 |
|
10.0400 |
1-7/8″ |
124.80 |
|
16.920 |
2-3/8″ |
203.04 |
|
14.920 |
2-1/4″ |
179.04 |
Yes, Hastelloy hex bars are highly resistant to high temperatures and can be used in extreme environments, including high-temperature applications in industries like chemical processing and aerospace.
Yes, Hastelloy hex bars can be recycled after use. Hastelloy, being a high-performance alloy, retains its properties even after recycling, making it a sustainable material for various applications.
Hastelloy hex bars are known for their excellent corrosion resistance, particularly against aggressive environments. However, in some extreme conditions, additional corrosion protection coatings may be applied for enhanced durability.
Hastelloy Hex Bars find extensive use in situations that require both form and function in extreme conditions. They are commonly utilized in reactors, heat exchangers, pressure vessels, and piping systems within chemical processing facilities. The hexagonal shape enhances grip and strength for fasteners, fittings, and machined components. In marine and offshore settings, Hastelloy effectively resists seawater corrosion, while in aerospace and nuclear applications, it can endure high temperatures and aggressive environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
