Semih Metals, located in Istanbul, Turkey, has made a name for itself as a top-notch manufacturer and supplier of high-quality Hastelloy Bars and Rods. With years of experience in providing high-performance alloys, the company ensures that its products meet rigorous international standards for durability, corrosion resistance, and strength. These Hastelloy Bars and Rods are specifically engineered to endure harsh chemical environments, extreme temperatures, and mechanical stress, making them perfect for a variety of industries. Semih Metals prides itself on precision engineering, consistent quality, and timely delivery, all aimed at ensuring customer satisfaction around the globe. Their dedication to excellence has established them as a reliable partner for critical applications that demand superior alloy materials.
Hastelloy Bars and Rods are nickel-molybdenum-chromium alloys, often enhanced with iron, tungsten, or cobalt, depending on the specific grade. They offer remarkable resistance to pitting, crevice corrosion, and stress corrosion cracking in both oxidizing and reducing environments. On the mechanical side, Hastelloy Bars and Rods boast high tensile strength, outstanding thermal stability, and excellent ductility, even in extreme conditions. These alloys maintain their structural integrity at high temperatures, providing hardness, toughness, and dependable performance in demanding applications across the chemical, aerospace, and marine sectors, where corrosion and thermal resistance are essential.
| Dimensions | DIN, EN, ASTM, JIS, ASME, BS, AISI |
|---|---|
| Hastelloy Round Bar size | Diameter: 3-~800mm |
| Hastelloy Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Hastelloy Bar Angle size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Billet Size | 1/2 to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Dimensions | Diameter / Height |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Stainless Steel Cold Drawn, Hot Rolled, Forged Round Bar,Cold Rolled, Rod |
| Processing | Bar cutting to 650mm |
| Form | Rod, Round, Channel Bar, T-Bar, Flat Bar, Precision Ground Bar, Blocks, Square, Rings, Round Rod, Triangle, Hollow, Rectangle, Threaded, Hex (A/F), Profiles, Half Round Bar, Ingot, Billet, I/H Bar, Forging etc. |
| Grade | UNS | Cr | Mo | Fe | C≤ | Si≤ | Co≤ | Mn≤ | P≤ | S≤ |
| B2 | N10665 | 1.0max | 26.0-30.0 | 2.0max | 0.02 | 0.10 | 1.0 | 1.0 | 0.04 | 0.03 |
| B3 | N10675 | 1.0-3.0 | 27.0-32.0 | 1.0-3.0 | 0.01 | 0.10 | 3.0 | 3.0 | 0.03 | 0.01 |
| X | N06002 | 20.5-23.0 | 8.0-10.0 | 17.0-20.0 | 0.05-0.15 | 1.0 | 0.5-2.5 | 1.0 | 0.04 | 0.03 |
| C22 | N06022 | 20.0-22.5 | 12.5-14.5 | 3.0-6.0 | 0.015 | 0.08 | 2.5 | 0.5 | 0.02 | 0.02 |
| C2000 | N06200 | 22.0-24.0 | 15.0-17.0 | 3.0max | 0.01 | 0.08 | 2.0 | 0.5 | 0.025 | 0.01 |
| C276 | N10276 | 14.5-16.5 | 15.0-17.0 | 4.0-7.0 | 0.01 | 0.08 | 2.5 | 1.0 | 0.04 |
| Mechanical properties | Tensile, min, ksi[MPa] | Yield, min, ksi[MPa] | Elongation, %(min) |
| B2 | 110[760] | 51[350] | 40 |
| B3 | 110[760] | 51[350] | 40 |
| X | 100[690] | 40[276] | 35 |
| C22 | 100[690] | 45[310] | 45 |
| C2000 | 100[690] | 45[310] | 45 |
| C276 | 100[690] | 41[283] | 40 |
Yes, Hastelloy Bars are highly corrosion-resistant, making them ideal for harsh environments, including chemical processing and marine applications. They resist pitting, crevice corrosion, and stress corrosion cracking effectively.
Yes, Hastelloy Rods can be customized in size and length to meet specific industry requirements. Their versatility ensures suitability for diverse applications.
Hastelloy bars perform exceptionally in high-temperature environments, offering thermal stability, oxidation resistance, and strength retention. They are ideal for demanding applications like chemical processing and aerospace.
Hastelloy Bars and Rods are extensively utilized in industries that require both corrosion resistance and strength in challenging environments. In chemical processing, they are commonly found in reactors, heat exchangers, and piping systems due to their ability to handle aggressive chemicals. In marine settings, they are used for pumps, valves, and fittings that come into contact with seawater and saline conditions. The aerospace industry relies on Hastelloy components for high-temperature gas turbines, engine parts, and exhaust systems. They are also employed in power generation, pollution control equipment, and pharmaceuticals.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
