Semih Metals, based in Istanbul, Turkey, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Carbon Steel Hex Bars and Rods. With years of experience in the steel industry, the company is known for its commitment to precision, durability, and dependable metal solutions. Semih Metals caters to both local and international markets, delivering products that not only meet global standards but also align with specific customer needs. Thanks to its state-of-the-art production facilities and rigorous quality control measures, Semih Metals guarantees consistency in every shipment, making it a go-to choice for industries that require strength, resilience, and trustworthy performance in their steel components.
Carbon Steel Hex Bars and Rods are mainly made up of carbon, iron, and small amounts of manganese, silicon, and other alloying elements, depending on the specific grade. The carbon content boosts hardness and tensile strength while ensuring good machinability. These products are known for their high yield strength, durability, and excellent wear resistance, making them perfect for heavy-duty applications. Their mechanical properties include outstanding toughness, rigidity, and the ability to handle stress in challenging conditions. Available in a variety of grades and sizes, they can be tailored to meet a wide range of engineering and industrial needs.
Carbon Steel Hex Bar Range: 3.17 MM TO 350 MM DIA
Steel Low Carbon Hexagon Rod Size: 2mm ~ 100mm
High CS Hollow Hex Bar Thickness : 50 – 6000 mm Long
Carbon Steel Hexagonal Bright Bar Technique :
Black Carbon Steel Hot Rolled Hex Bar Benefits :
| Grade | Mn | Si | C | Cr | P | Ni | S | Mo | Cu | fe | Vanadium (max) | Niobium (max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| EN19 | .50 to .80 | .10 to .35 | .35 to .45 | .90 to 1.40 | .04 | to | .04 | .20 to .40 | ||||
| EN-9 | .50 to .80 | .05 to .35 | .50 to .60 | .040 MAX | .040 MAX | |||||||
| A36 | 1.03% | .28% | .25 – .290 % | .04% | .05% | .20% | 98.00% | |||||
| A105 | .60-1.05 | .10- .35 | .35 | .3 | .035 | .4 | .04 | .12 | .4 | .08 | .02 | |
| A353 | .50 to 1.00 | .10 to .35 | .10 to .20 | .75 to 1.25 | Max .040 | 1.00 to 1.50 | Max .040 | .08 to .15 | ||||
| EN 47 | .50- .80% | .50% max | .45- .55% | .80-1.20% | .06% max | .06% max | ||||||
| EN 45 | .50 to .90% | 0/1 to .35 | .75 to .90% | .04% Max | .04% Max | |||||||
| EN24 | .45 – .70 | .10 – .35 | .36 – .44 | 1.00 – 1.40 | Max .035 | 1.30 – 1.70 | Max .040 | .20 – .35 | ||||
| Grade | Yield Strength, | Tensile Strength, | Elongation at Break (in 50 mm) | Bulk Modulus (typical for steel) | Modulus of Elasticity | HBW | Poissons Ratio | Fatigue strength coefficient, of (Mpa) | Shear Modulus | Impacting Energy | Reduction of area, min: |
|---|---|---|---|---|---|---|---|---|---|---|---|
| a36 | 250 MPa | 400 – 550 MPa | 23.00% | 140 GPa | 200 GPa | 0.26 | 79.3 GPa | ||||
| 36300 psi | 58000 – 79800 psi | 23.00% | 20300 ksi | 29000 ksi | 0.26 | 11500 ksi | |||||
| EN45 | 35 (241) | 80 (551) | 40% | 204 Gpa | 948 | ≥63 | |||||
| EN19 | ≥930 Mpa | ≥1080 Mpa | ≥12 | 217 | ≥45 | ||||||
| 105 | 36,000 psi [250 MPa] | 70,000 psi (485 MPa] | 187 | 30% min | |||||||
| EN8 | ≥210 | ≥380 | ≥25 | ≤111HB | ≥50 |
Yes, carbon steel hex bars can attract magnets because carbon steel is a ferromagnetic material, meaning it has magnetic properties and can be magnetized.
Yes, carbon steel hex bar can be recycled after use. It is highly recyclable and can be melted down and reused in the production of new steel products without losing quality.
Carbon steel hex bars and rods come in various grades, including mild steel, medium carbon steel, and high carbon steel. Common types include ASTM A36, A105, A529, A992, and 1045.
Due to their versatility and strength, Carbon Steel Hex Bars and Rods find applications in numerous industries. In construction, they are used in frameworks, fasteners, and reinforcement components. The automotive sector relies on them for producing shafts, nuts, bolts, and precision-machined parts. In machinery and equipment manufacturing, these bars offer reliable structural support and wear resistance. They are also essential in the oil, gas, and petrochemical industries, where durability and strength are crucial. Their hexagonal shape makes them easy to grip and apply torque in fastening applications, making them ideal for mechanical assemblies, heavy-duty tools, and high-strength engineering components.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
