Semih Metals, located in Istanbul, Turkey, is a leading manufacturer and supplier of high-quality metal products, including Alloy C263 bars and rods. Semih Metals has a commitment to excellence and offers a wide range of alloy products tailored to meet the demands of industries such as aerospace, chemical, and energy. Alloy C263 is used for critical applications where strength, corrosion resistance, and high-temperature stability are very important. Semih Metals are known for precision, reliability, and customer satisfaction in offering the best material solutions to clients around the world.
Alloy composition of C263 bar and rod includes 52% Nickel, 19-21% Chromium, 15-17% Cobalt, 5.0-6.0% Molybdenum, 1.5-2.5% Tungsten, with some Aluminum, Iron, and Titanium. The alloy has shown promise in providing excellent oxidation and corrosion resistance in the high-temperature environment. The mechanical properties were reported as having excellent strength, high fatigue properties, and good weldability. Typically, tensile strength in C263 will be around 130-150 ksi (895-1035 MPa). The yield strength will be near about 80-100 ksi (550-690 MPa). Elongation ranges at a minimum of 20%. It finds widespread application in aerospace and in turbine applications.
| Standards : | AMS 5872 |
| Size Range : | 0.015″ Thk up to 2″ Thk |
| Thickness : | Range from .008″ to .0125″ |
| Length : | 2m, 2.44m, 3m, or as required |
| Width : | 10-2500mm |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Nimonic 263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Grade | Material Sheet | Temperature °C | Yield Strength 0.2 % (MPa) | Tensile Strength (MPa) | Elongation (%) | Hardness HV |
| Nimonic 263 | Nimonic 263 Round Bar Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Nimonic 263 Round Bar Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | – | |
| Nimonic 263 Round Bar Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
| STANDARD | WERKSTOFF NR. | UNS |
| Nimonic 263 | 2.4650 | N07263 |
Yes, Alloy C263 bars are recyclable. As a high-performance alloy, it can be melted and reused for manufacturing new products, making it an environmentally friendly material in the long term.
Alloy C263 rods are available in various sizes ranging from 1/8" to 6" in diameter, with lengths typically up to 12 feet. Common finishes include hot-rolled, cold-drawn, and polished.
Yes, Alloy C263 (also known as Hastelloy C263) can be welded using appropriate techniques such as TIG or MIG welding, with careful control of heat to avoid carbide precipitation.
Alloy C263, also referred to as UNS N08028, is a nickel-chromium-iron alloy that has great resistance to oxidation, corrosion, and high temperature. It finds applications in aerospace, chemical processing, and power generation industries. The alloy has a special value in applications involving resistance to sulfuric acid, hydrochloric acid, and phosphoric acid, which qualifies it for the use in heat exchangers, reactors, and furnace components. Alloy C263 bar and rod is also applied on components of the turbine engine, petrochemical equipment, and marine applications. Due to its elevated temperature strength and resistance to aggressive environments, this alloy is highly suitable for demanding applications in both industrial and high-performance environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
