Semih Metals, based in Istanbul, Turkey, is a leading manufacturer and supplier of high-quality metals. One of their specialized products is Alloy 20 Forgings. Alloy 20 is a nickel-iron-chromium alloy known for its excellent resistance to corrosion, especially against acids. The forging process makes the material stronger and more reliable for industrial use. Semih Metals ensures that every Alloy 20 Forging meets international quality standards. These forgings are widely used in industries where strength and resistance to harsh chemical environments are important. Customers can trust Semih Metals for consistent quality and timely delivery..
Alloy 20 Forgings are mainly made of nickel, iron, and chromium, with small amounts of copper and molybdenum. This combination makes the material strong, tough, and highly resistant to corrosion, especially from sulfuric acid. The forging process improves its mechanical properties, giving it high tensile strength, good hardness, and excellent durability. Alloy 20 Forgings can handle high pressure and temperature without deforming. Semih Metals ensures that each forging is produced with uniform composition and tested for strength and corrosion resistance, providing reliable performance for industrial applications.
| Specifications | ASTM B462, ASME SB462 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3.00 – 4.00 | 32.00 – 38.00 | 19.00 – 21.00 | 29.85 min* | 2.00 – 3.00 | 0.045 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
| STANDARD | WERKSTOFF NR. | UNS | EN | AFNOR |
| Alloy 20 | 2.4660 | N08020 | NiCr20CuMo | Z2NCUD31-20AZ |
Yes, Alloy 20 forgings are highly resistant to corrosion, particularly against sulfuric acid, making them ideal for chemical processing environments. Their excellent resistance ensures durability and longevity in harsh conditions.
The maximum operating temperature for Alloy 20 forgings is typically around 1000°F (537°C). However, it is important to consider application conditions and potential stress factors to ensure optimal performance.
Yes, Alloy 20 forgings can be customized for specific applications. They are tailored to meet unique requirements, offering excellent corrosion resistance, durability, and strength for various industrial uses.
Alloy 20 Forgings are widely used in industries where resistance to chemicals and corrosion is critical. They are commonly found in chemical processing plants, oil and gas equipment, valves, pumps, and heat exchangers. These forgings are ideal for making flanges, fittings, and machinery parts that must withstand acidic and harsh environments. Semih Metals provides Alloy 20 Forgings that are strong, durable, and easy to work with. Their high quality ensures long-lasting performance in chemical, petrochemical, and marine applications. Customers trust these forgings for safe and reliable operations in demanding industrial settings.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
